    Sinexcel ISUNA Series
    Three phase hybrid inverter
  • 5-20kW
  • 2 MPPT
    • Three-phase hybrid inverter is compatible with a wide range of high voltage batteries, widelyused for residential rooftops and small-size commercial applications.
    Features
    Max. 15 units
    High scalability
    98.4%
    Max. efficiency
    Advanced sic technology
    Smart load control
    Leakage current protection
    150%
    PV configuration
    110%
    output overload
    180-960V
    Wider MPPT voltage range
    APP+H5
    data visible smart data analysis
    Datasheet
  • Model Name
  • Isuna 10000T
  • Isuna 20000T
    • Off-grid Output
    Norminal Output Power10kW20kW
    Max. Output Power11kVA22kVA
    Peak Power-Timeframe11kVA-60s22kVA-60s
    Nominal Output Voltage3/N/PE, 220/380V, 230/400V, 240/415V
    On-grid Parameter
    Norminal Output Power10kW20kW
    Max. Output Power11kVA22kVA
    Max. Input Power from Grid20kVA40kVA
    Max. Input Current from Grid30A60A
    Max. Output Current16A32A
    Nominal Output Voltage3/N/PE, 220/380V, 230/400V, 240/415V
    Grid Voltage Range184-276V(P2N)
    PV Input
    Max. Input Power15000Wp30000Wp
    Max. Input Voltage1000V
    Number of MPPTs22
    Number of Max. input strings per MPPT22
    MPPT Operating Voltage Range180V-960V
    Full Load MPPT Operating Voltage Range280-850V450-850V
    Nominal Input Voltage600V
    Short-Circuit Current20A/20A30A/30A
    Starting Voltage200V
    Max. Input Current17.5A/17.5A25A/25A
    Battery Parameter
    Battery TypeLithium-ion
    Number of Battery Input12
    Battery Voltage Range150-800V180-800V
    Full Load Battery Voltage Range400-800V
    Peak Charging/Discharging Current Duration35A(60s)35A/35A(60s)
    Nominal Charging/Discharging Power10600W20000W
    Max. Charging/Discharging Current30A25A/25A
    Efficiency
    Max. Efficiency98.40%98.20%
    European Efficiency97.90%97.70%
    Max. Battery Charging Efficiency97.80%
    Max. Battery Discharging Efficiency97.80%
    General Data
    Size(L*W*H)577mm*537mm*250mm577mm*537mm*250mm
    Weight28kg28kg
    Noise<30dB(A)<45db(A)
    Operating Temperature Range-25 ℃~+60 ℃
    Cooling MethodNatural CoolingAir Cooling
    Ingress Protection GradeIP65
    Communication PortCommunication Port
    MonitoringWIFI/4G/GPRS/RS485
    ProtectionDC Switch, PV Insultion Resstance Detection, AC Overvoltage Protection, AC Overcurrent Protection, ACShortCircuit Protection, Anti-islanding Protection, Residual Current Monitoring, PV Insulation ResistanceDetection, Surge Protection, PV Reverse Polarity Protection
    Certification
    CE_LVDIEC 62109-1:2010，IEC 62109-2:2011，EN 62109-1:2010，EN 62109-2:2011
    CE_EMCEN61000-6-1,EN61000-6-2,EN61000-6-3,EN61000-6-4
    GridVDE-AR-N 4105, VDE V 0126-1-1, G98/G99, CEI 0-21, EN50549, RD 1699, NRS 097-2-1, AS 4777.2, R25
